KHS Winslow

KHS Winslow
  • Color: Black
  • Color: Red
$699.00
Please select options
This item is not permitted to be shipped, however it can be purchased online and picked up at your convenience. We will contact you when your order is ready.

Details

Mountain bikes are just that, a bike to take to off road into the mountains. These bikes typically have suspension forks and/or rear suspension. KHS makes Mountain bikes that give you a comfortable fit to help you be able to get and ride all day long.

Geometry Chart:
X-Small/13Small/15Medium/17Large/19X-Large/21
s/t c-t 330/13 381/15 432/17 483/19 533/21
H/t° 67° 67.5° 67.5° 67.5° 67.5°
s/t° 73° 73° 73.6° 73.6° 73.6°
t/t effectv 553/21.8 594/23.4 610/24 632/24.9 659/25.9
c/s 440/17.3 440/17.3 435/17.1 435/17.1 435/17.1
BB Height 295/11.6 295/11.6 314/12.4 314/12.4 314/12.4
s.o. 709/27.9 730/28.8 793/31.2 825/32.5 846/33.3
h/t L 90/3.5 90/3.5 100/3.9 115/4.5 130/5.1
Stack 583/23 585/23 617/24.3 631/24.8 624/24.6
Reach 375/14.7 415/16.4 421/16.6 445/17.5 472/18.6

Specs

Frame 6061 Aluminum w/Custom Formed T/T & D/T, w/Replaceable Derailleur Hanger, XS-S:27.5”, M-XL:29”, Internal Cable Routing
Fork SR XCT30, HLO. 100mm, Hydraulic Lock-Out, Preload Adjust, XS-M:27.5”, L-XL:29”
Rims XS-S: Aluminum Disc Double Wall, 27.5x32H, M-XL: 29x32H
Hubs Front: Aluminum Disc w/CNC Rotor Flange, QR
Rear:
Spokes 14G Black 32x32
Tires XS-M: Kenda Saber Pro, 27.5x2.25", L-XL: 29x2.25"
Bottom Bracket Outboard Cartridge Bearing
Crankset Aluminum 2-pc, 32T, Narrow/Wide, XS-M:170, L-XL:175
Front Derailleur S-Ride, SL-M300C, 9-Speed
Rear Derailleur S-Ride, RD-M300C, 9-Speed
Cassette/Freewheel CS-M300C, 11-42T, 9-Speed
Chain KMC X9 w/MissingLink
Brakes Shimano MT200 Hydraulic Disc, 180/160mm: 27.5”, 180/160mm: 29” Rotors, Wave 12
Brake Levers Shimano BL-MT200
Handlebars KHS Aluminum Riser, 31.8mm, 720x20mm; Ladies: 680x20mm
Tape/Grips Q2 Lock-on
Stem KHS Aluminum Threadless 4-bolt, 6-degree, 31.8mm, XS-S:60mm, M:75mm, L-XL:90mm
Headset Threadless Zero Stack, 1-1/8"
Seatpost KHS Aluminum Micro-Adjust 31.6mm
Saddle KHS Sport
Pedals Resin ATB Platform w/DU Bearings

* Subject to change without notice.

Part Numbers

Option UPC MPN
Black / X-Small 756928937170 42-1435
Black / Small 756928937187 42-1440
Black / Medium 756928937200 42-1445
Black / X-Large 756928937248 42-1455
Red / Small 756928937194 42-1460
Red / Large 756928937231 42-1470
